hexo-theme-mdui document English version
Posted: Mar 23, 2017
Last Modified: May 06, 2017
  • Article QR Code
This article was last modified days ago. The content of this post may be outdated!

This is hexo-theme-mdui document English version

您可以在这里找到中文版本.

I write this theme for my personal use, but if you want to use it too, please clone my theme and follow this document to properly configure it.

This document follows the _config.yml configurations order. If the doc doesn’t mention some configurations, just ignore them, I will remove them in later development.

Install

Install the theme

You need following things:

  • a hexo
  • my theme

The theme just supports git clone, npm install will be supported later (or not supported).

$ git clone https://github.com/Halyul/hexo-theme-mdui.git

Once you have finished clone, copy the folder to hexo theme foler , and rename to mdui

The folder name can be changed to whatever you want, but needs to match the name below.

Enable the theme

Then open hexo’s _config.yml, find theme and change to folloing name to mdui(or the one you have set just now.)

Then run the following code to install prismjs in the hexo folder to prevent from getting errors when you run hexo

npm install prismjs --save

Run hexo s --debug in terminal, open http://localhost:4000 to make sure the site is running without any problems.

Config

location

  • location: For Mathjax. available option is cn, for the users in China Mainland to access a better cdn service. For users who are not in China Mainland, the theme uses Cloudflare cdn service.

style

  • bg_img: parallax image in archive page
  • avatar: author’s avatar
  • slogan: author’s slogan/description
  • hoverable: all the cards can hover or not

HTML Head

Here you can set HTML head information.

  • favicon
  • high_res_favicon: high resolution favicon
  • high_res_favicon: iOS luncher icon
  • keywords: website keywords.

Color

Setting up the theme color.

  • primary_color: Primary color

  • accent_color: Accent color

  • layout: Layout

  • random: random color, available options are global (global site random color, namely every time you generate or deploy you blog, every pages’ color in the blog will change to another.) and post(only the post color will change)

    If you define a color in post’s fort-matter, the defined color takes precedence over the random color.
    for some reasons, when the option is post, the custom pages’ color would change.

  • bg_color: Global background color (needs to be set as HEX format)

For now, the Android Chrome status bar color changing does’t support the color with color scale.
For some reasons again (lol), please change the space to - when you use the color.
eg. deep purple -> deep-purple

Primary colors

red pink purple deep-purple indigo blue light-blue cyan teal green light-green lime yellow amber orange deep-orange brown grey

Accent colors

red pink purple deep-purple indigo blue light-blue cyan teal green light-green lime yellow amber orange deep-orange

Layout

The theme has two layouts, the default layout is white, you change use the dark layout.

  • layout: “dark”

appbar

  • title: This is the default title in the appbar, it will always show, and will not change or hide, you can leave it blank

    Personally, I’m not recommend you leaving it blank, because it provides a go-to-index-page function.
    you can find a back button in the appbar when you visit some page, this button just provides a return function, which is the as the browser provided.

Also, the header in the drawer uses this setting.

post

  • entry_excerpt: how many posts summary words will be displayed in the index page.
  • qr_code: posts/pages’ qr code, for more information, please click here
  • prism: code highlight
    • theme: internal theme setting, including default, coy, dark, funky, okaidia, solarizedlight, tomorrow, twilight
    • line_number: whether show line numbers before the code, available options are true and false
  • donate: post donate, please configure it with the examples. How to use icons please click here

share_menu

Setting uo the share menu. If you don’t need any share options, please remove following contents and set share_menu: false

  • rss: article rss, the link is the same as the path in hexo _config.yml under feed, available options are true and false, more detailed click here.
  • weibo: Sina Weibo, available options are true and false
  • twitter: Twitter, available options are true and false
  • facebook: Facebook, available options are true and false
  • googleplus: Google+, available options are true and false
  • linkedin: Linkedin, available options are true and false
  • qq: QQ, available options are true and false
  • telegram: Telegram, available options are true and false

comment

comment service plugin, available options are disqus and custom

  • use: disqus or custom
  • shortname: disqus short name, for example, example.disqus.com, so short name is example, if use: custom, this line is unavailable

If you want to use the comment service that I haven’t add support, please click here for how to configure

pagination

Pagination setting

  • show: after how many pages the number will be hidden. eg. the original pagination is 1 2 3 4 5 6, then show: 2, the pagination will change to 1 2 ... 5 6
  • since: specify the date when the blog was setup

    I haven’t add a judgement here, it will lead to following problem.
    If your blog was setup in in 2017, and the year now is 2017, so the copyright will display 2017 - 2017, please avoid this.

  • ICP: this is for users who are in China Mainland to show his/her ICP number.

pages

How to use icons please click here

uncategorized pages

Custom pages setting, please follow format which is left in the _config.yml or the one below.

- Test1:
  - link: "/test1"
  - icon: "``"

These lines will generate an entrance of a link called Test1, links to yoursite.com/test1, and the icon is .

categorized pages

Custom pages support the pages which belong to the same category to be shown under a section, if you wants to enable it, please configure it with the format that the left in the file.
Key option is cascade: true

sns

Here you can set up your contact information, please follow the format that left in the file. How to use icons please click here

or you can fill false to disable.

Twitter:
    link: https://twitter.com
    fa: 'fa-twitter'

Vendor

The css and js files haven’t cdn service support, so they are accessed from your server directly. If you have your own cdn service, you can do following configurations.

  • style_min_css: direct address
  • js_min_js: direct address
  • outdatedbrowser_min_js: direct address

Through this feature you can modify the css and js.

Plugins

busuanzi

busuanzi is a plugin to count how many page views and unique visitors.
If you don’t need it, please delete following lines and set busuanzi: false

  • all_site_uv: All site unique visitors
  • post_pv: how many times the page has been viewed
  • busuanzi_pure_mini_js: busuanzi js address, it is hosted in China Mainland.

For now, this cant be disabled. Please install hexo-generator-search to prevent errors.

$ npm install hexo-generator-search --save

more details can be found here

Mathjax

If your post or page needs Mathjax, please add mathjax: true in the font-matter.

Advanced settings

Custom css and js

If you want to add some custom code like font-face, Google Analytics, etc., please create a custom folder in the layout folder in theme folder, then create a custom_head.ejs file (the code inside goes before </head> ) or a custom_js.ejs file (the code inside goes before </body> ) to put your own code.

ICONS

The theme supports font awesome icons and Material icons. Add fa: to the option that you want to use font awesome icons.

You can find icons here

Add md: to the option that you want to use Material icons.

For icons that support modern browsers, you can find from here. When you find the one you need, click it, and copy the characters after https://material.io/icons/#ic_
For icons that support all mainstream browsers, you can find from here, but the site hasn’t an English version. You can just browse the icon list or search an icon, click the one you need, copy the characters like &#xe84d;.

Add null_icon: true as a placeholer.

lightgallery

unspported now
Lightgallery is a gallery plugin, you can see what it can do just click the following picture.

RSS

If you need rss, please install hexo-generator-feed

$ npm install hexo-generator-feed --save

more details can be found here.

service_worker

The theme has internal Service Worker support, if you need this feature, please open source/sw.js in the THEME FOLDER, and configure ignoreFetch to match your site setting, for more information, please google or yahoo; then, create a offline.md under source in the HEXO FLODER, the format is the same as the hexo markdown

available options are true and pwa

  • true: only inject Service Worker
  • pwa: The site supports Google’s Progressive Web Apps

If you use pwa, please open source/manifest.json in the THEME FOLDER to configure, for how to configure please google or yahoo.

archive page

about_me

This is the about dialog in the archive page. If you need it, please create about.yml under source/_data in the HEXO FOLDER, and choose a following format to fill in. You can directly copy and paste to see the style.

Options:

slogan: show the slogan/description or not, available options is `true`, or just leave it blank.
others: the text under slogan/description. (these two options are independent)
  - '1'
  - '2'

Format 1:

hellow:
  main:
    hi:
      content: xxxxxx
      s_img: /img/avatar.png
    hi1:
      content: xx
      link: //google.com
      s_img: /img/favicon.png
    hi2:
      content: aaaa
  more:
    hi3:
      content: '561456415341'
      link: //google.com
      s_img: /img/favicon.png
    hi4:
      content: 'xxxxxxx'
      s_img: /img/favicon.png

Format 2:

hellow1:
  main:
    hi:
      content: xxxxxx
      one_line: true
    hi1:
      content: xx
      fa: 'fa-beer'
    工作經歷:
      content: xxxx
      content_1: Designer & Developer,2222
  more:
    hi3:
      content: '1111'
      one_line: true
      s_img: /img/favicon.png
    hi4:
      content: '1111'
      one_line: true
      c_img: /img/favicon.png

Format 3:

hellow2:
  main:
    hi:
      content: xxxxxx
      one_line: true
      md: 'home'
    hi1:
      content: xx
      link: 'xxxx/xxx'
      fa: 'fa-beer'
    工作經歷:
      content: xxxx
      content_1: Designer & Developer,2222
  more:
    hi3:
      content: '1111'
      one_line: true
      null_icon: true
    hi4:
      content: '1111'
      one_line: true
      fa: 'fa-qq'

Some options meaning:

  • one_line: single line content, if this is true, the text in content: will not be rendered.
  • fa/md/null_icon: How to use icons please click here
  • content_1: text that below the text from content:
  • link: web address
  • s_img: square picture that shows before the section content.
  • c_img: circular picture that shows before the section content.
random_pics

The random pictures on the Categories, Tags, Years in the archive page(defining a certain picture is not supported). Those pictures are stored in source/img/random in the THEME FOLDER. If you add picture(s), change the total pictures number.
Only `jpg is supported

Post

QR_CODE

QR Code for posts and custom pages, available options are true and false, you need to install hexo-helper-qrcode plugin to enbale the feature. Please run following command in terminal in hexo folder.

$ npm install hexo-helper-qrcode --save

Thumbnail

Post and custom page support thumbnail.

  • thumbnail: By using this method, the post thumbnail will be showed between post title and post content.

Custom primary &/ accent color in post and custom page

When you write post, add primary_color and/or accent_color in the font-matter can change this post’s theme color. Colors name is the same as Color
eg.

title: This is title
primary_color: grey
accent_color: red
-----------

No comment, No category, No tag

add following content to font-matter to disable comment, disable category, disable tag

  • comment: set it false to disable comment
  • category: set it false to disable category
  • tag: set it false to disable tag

Pinned Post

Just add pinned: true to font-matter to pin the post to top

customComment

please open layout/custom/custom_comment.ejs in the theme folder, and paste the comment service code to this file.
If the comment service needs you to set the source id (or something like that) of the page, please fill it with <%- config.url + config.root + page.path %>

Custom pages

Friends page

Enter the source folder in hexo folder, create a folder with the name you like, then enter it and create a index.md file, fill it with following content

---
title: MY FRIENDS
layout: friends
header: header of friends page, can be left blank
---

then go back to the source folder, enter the _data folder (if there isn’t any, please create one), and create a file called friends.yml (the name can’t be changed), using following format to creat links.

Example:
    link: Site address
    avatar: Avatar
    descr: Slogan or descrpition

Gallery supports multi album and single album.

multi album

Create a galleries.yml in source/_data in the HEXO FOLDER, and configure it with following format.
And add a custom page anywhere in source in the HEXO FOLDER, and fill layout: galleries

Albun name:
  link: URL
  descr: album description or something else
  bg: default image
  logo: this can be ignored, a circular image, configure to see what the style like.
single album

Please create a custom page anywhere in source in the HEXO FOLDER, and fill layout: gallery, then add photos: with following format in the font-matter

photos:
  x:
    img: /img/bg.png
    descr: 'description goes here'

Configure to see what the style like.

Known issues

Using hexo-neat plugin

Because hexo-neat plugin will add note when it neats the files, this will break the Android Chrome status bar color changing, if you want to/ are using this plugin, please do following modifications.

Enter the node_modules folder in the hexo folder, find and enter hexo-neat folder, then enter lib folder, use your editor open filter.js, find following code and delete

The number of rows for reference only, please seach the code

Line 31, 32

var prefix = '<!-- build time:' + Date() + " -->";
var end = '<!-- rebuild by neat -->';
result = prefix + result + end;

Line 58, 59

var prefix = '/* build time:' + Date().toLocaleString() + "*/\n";
var end = '\n/* rebuild by neat */';

Line 87, 88

var prefix = '// build time:' + Date().toLocaleString() + "\n";
var end = '\n//rebuild by neat ';

Find the following codes and modify
The number of rows for reference only, please seach the code

Line 60

var css_result = prefix + result.styles + end;

change to

var css_result = result.styles;

Line 89

var js_result = prefix + result.code + end;

change to

var js_result = result.code;
Article License: CC BY-NC-SA 4.0
Article Permalink: https://halyul.github.io/posts/mdui-doc-en/
Article Markdown: https://halyul.github.io/posts/mdui-doc-en/mdui-doc-en.md
  1. 1. Install
    1. 1.1. Install the theme
    2. 1.2. Enable the theme
  2. 2. Config
    1. 2.1. location
    2. 2.2. style
    3. 2.3. HTML Head
    4. 2.4. Color
      1. 2.4.1. Primary colors
      2. 2.4.2. Accent colors
      3. 2.4.3. Layout
    5. 2.5. appbar
    6. 2.6. post
    7. 2.7. share_menu
    8. 2.8. comment
    9. 2.9. pagination
    10. 2.10. footer
    11. 2.11. pages
      1. 2.11.1. uncategorized pages
      2. 2.11.2. categorized pages
    12. 2.12. sns
  3. 3. Vendor
  4. 4. Plugins
    1. 4.1. busuanzi
    2. 4.2. search
    3. 4.3. Mathjax
  5. 5. Advanced settings
    1. 5.1. Custom css and js
    2. 5.2. ICONS
    3. 5.3. lightgallery
    4. 5.4. RSS
    5. 5.5. service_worker
    6. 5.6. archive page
      1. 5.6.1. about_me
      2. 5.6.2. random_pics
  6. 6. Post
    1. 6.1. QR_CODE
    2. 6.2. Thumbnail
    3. 6.3. Custom primary &/ accent color in post and custom page
    4. 6.4. No comment, No category, No tag
    5. 6.5. Pinned Post
    6. 6.6. customComment
  7. 7. Custom pages
    1. 7.1. Friends page
    2. 7.2. Gallery
      1. 7.2.1. multi album
      2. 7.2.2. single album
  8. 8. Known issues
    1. 8.1. Using hexo-neat plugin
Newer Post
fkshort
Older Post
解决Hexo MODULE NOT FOUND问题
Buy me a beer?
Your browser is out-of-date!

Update your browser to view this website correctly. Update my browser now

×
